Chapter 7: Building the Trunk with the Default 10Gbps Stacking Ports
156
Adding Ports 49 and 50 on the x530L-52GPX or x530L-52GTX Switch
to the Stack Trunk
This procedure explains how to add ports 49 and 50 to the stack trunk on
the x530L-52GPX or x530L-52GTX switches. The procedure assumes the
following:
You performed the procedures earlier in this chapter to power on
and verify the stack with ports 51 and 52 as the stack trunk.
Ports 49 and 50 are not cabled. If there are cables connected to
the ports, remove them before performing the procedure.
To add ports 49 and 50 to the stack trunk, perform the following
procedure:
Table 21. Adding Ports 49 and 50 to the Stack Trunk on the x530L-52GPX or x530L-52GTX Switch
Step Description and Command
1 Start a local management session on any switch in the stack. Refer to “Starting a
Local Management Session” on page 150.
2 Move to the Privileged Exec mode with the ENABLE command.
awplus> enable
3 Move to the Global Configuration mode with the CONFIGURE TERMINAL command.
awplus# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
4 Enter the port Interface mode for ports 49 and 50 on all the switches in the stack. This
example assumes the stack has four switches:
awplus(config)# interface port1.0.49-1.0.50,port2.0.49-
2.0.50,port3.0.49-3.0.50,port4.0.49-4.0.50
5
Designate the ports as stacking ports with the STACKPORT command.
awplus(config-if)# stackport
% Save the config and restart the system for this change to take
effect.
6
Return to the Global Configuration mode.
awplus(config-if)# exit
7
Return to the Privileged Exec mode.
awplus(config)# exit
