x530L Series Installation Guide for Virtual Chassis Stacking
27
Twisted Pair Ports
The specifications of the twisted pair ports are listed in Table 2 through
Table 7 on page 32.
Table 2. x530L-10GHXm Switch Twisted Pair Port Specifications
Specification Description
Port Speed Ports 1 - 8: 100Mbps or 1/2.5/5Gbps.
100Mbps: Set the port speed manually or with
Auto-Negotiation.
1/2.5/5Gbps: The port speed is set with Auto-
Negotiation only.
The default is Auto-Negotiation for all ports.
Duplex Mode Ports 1 - 8:
100Mbps: Full- or half-duplex mode.
1/2.5/5Gbps: Full-duplex mode only.
Supports Auto-Negotiation at 100Mbps.
Maximum Distance 100 meters (328 feet)
Power over Ethernet
PoE (15.4W maximum per port) / 8 PDs
PoE+ (30W maximum per port) / 8 PDs
PoE++(60W maximum per port) / 8 PDs
PoE++(90W maximum per port) / 5 PDs
Maximum Power Budget 500W
PoE Mode
Classes 0-4 (Type 1 or 2 up to 30W):
Mode A (MDI-x)
Classes 5-6 (Type 3 up to 45W/60W):
Mode A (MDI-x) plus Mode B (MDI-x,
MDI)
Classes 7-8 (Type 4 up to 75W/90W):
Mode A (MDI-x) plus Mode B (MDI-x,
MDI)
Connector 8-pin RJ-45
