x530L Series Installation Guide for Virtual Chassis Stacking
171
Steps 3 and 4 remove the stacking function from the default stacking ports 9 and 10 on the
provisioned member switches.
3
Enter the port Interface modes of the default stacking ports 9 and 10 on the provisioned
member switches. The example here assumes there are three provisioned member
switches, with the IDs 2 to 4:
awplus(config)# interface port2.0.9-2.0.10,port3.0.9-3.0.10,port4.0.9-
4.0.10
4
Remove the stacking function from the ports to convert them into regular Ethernet ports,
with the NO STACKPORT command:
awplus(config-if)# no stackport
% Save the config and restart the system for this change to take effect.
Steps 5 and 6 add the stacking function to the selected 5Gbps trunk ports on the provisioned
member switches.
5
Enter the Interface modes of the 5Gbps ports to be used as the stack trunk on the
provisioned member switches. If you filled out the worksheet on Table 18 on page 85,
refer there for the stacking ports. This example assumes that there are three member
switches that are to use ports 7 and 8 as the stack trunk.
awplus(config)# interface port2.0.7-2.0.8,port3.0.7-3.0.8,port4.0.7-
4.0.8
6
Designate the ports as stacking ports with the STACKPORT command.
awplus(config-if)# stackport
% Save the config and restart the system for this change to take effect.
Steps 7 to 13 save your changes on the master switch and reboot it.
7
Return to the Global Configuration mode.
awplus(config-if)# exit
8
Return to the Privileged Exec mode.
awplus(config)# exit
9
Enter the WRITE command to save your changes.
awplus# write
Building configuration ...
[OK]
Table 23. Configuring the Master x530L-10GHXm Switch for 5Gbps Stacking Ports – Part II
Step Description and Command
To Next Page
