Chapter 1: Overview
30
Table 5. x530L-28GPX Switch Twisted Pair Port Specifications
Specification Description
Port Speed Ports 1 - 24: 10Mbps, 100Mbps or 1Gbps.
10Mbps/100Mbps: Set the port speed
manually or with Auto-Negotiation.
1Gbps: The port speed is set with Auto-
Negotiation only.
The default is Auto-Negotiation for all ports.
Duplex Mode Ports 1 - 24:
10Mbps/100Mbps: Full- or half-duplex
mode.
1Gbps: Full-duplex mode only.
Supports Auto-Negotiation at 10Mbps and
100Mbps.
Maximum Distance 100 meters (328 feet).
Power over Ethernet PoE (15.4W maximum per port) and
PoE+ (30W maximum per port).
Maximum Power Budget 740W (370W per power supply).
PoE Mode Classes 0 to 4: Mode A
Connector 8-pin RJ-45.
