1–2 Copyright © 1996 General Motors Corp.
AT 500, 1500 SERIES AUTOMATIC TRANSMISSIONS
Figure 1–1. AT 1545 Automatic Transmission — Left-Front View
Figure 1–2. AT 545R Automatic Transmission — Right-Rear View
SHIPPING BRACKET
MODULATOR
RETAINER
SELECTOR
SHAFT
WELDED
TORQUE
CONVERTER
ASSEMBLY
(NOT SEPARABLE)
OIL PAN
GOVERNOR
COVER
BREATHER
H01341
RETARDER CONTROL
VALVE ASSEMBLY
NAMEPLATE
OUTPUT SHAFT
BRAKE MOUNTING
PAD
OIL FILLER
TUBE PORT
DRAIN PLUG
BREATHER
H02874
