Page #76 background image
4–8 Copyright © 1996 General Motors Corp.
AT 500, 1500 SERIES AUTOMATIC TRANSMISSIONS
c. Mechanic’s Tools, Shop Equipment
. The
following tools, in addition to the common tools ordi-
narily required, should be available:
Snapring pliers
Micrometer
Depth micrometer
Dial indicator set
Headless guide bolts M6-1 x 80 mm (2)
Headless guide bolts,
5
16
-18 x 4 inch (2)
Suitable hoist —
1
2
ton (500 kg) capacity
J 33184*** 4–3 35 Fourth clutch hub drilling fixture NR
J 33410 4–3 41 Neutral start switch wrench 7–12
e
J 34127 4–3 45 Selective snapring gauge for center support (used
with J 23717-C)
7–5
b
J 34814 4–4 66 PTO backlash gauge 7–14
b
J 38086-1 NI NI Remover leg (3) (used with J 24420-B) (use if bearing
is a 9-ball bearing)
3–16
c
J 38460-A 4–4 74 Digital protractor NR
J 39735 4–4 62 Center support bushing installer (AT 1500 Series
only)
6–13
c
J 39736-01 4–2 11 Sun gear shaft retainer (AT 1500 Series only) 7–6a, b
J 39736-02 4–2 12 Thumb screw for J 29736-01 (AT 1500 Series only) 7–6a
J 39737 4–2 6 Sun gear shaft bushing installer (AT 1500 Series only) 6–14b
J 39738 4–3 43 Pump support assembly remover (AT 1500 Series
only)
5–3i
J 39739 4–4 76 Oil pump bushing installer (AT 1500 Series only) 6–9d
J 39757 4–2 2 Oil pump seal installer (AT 1500 Series only) 6–9d
J 39794 4–2 4 Stator shaft rear bearing installer (AT 1500 Series
only)
6–9d
J 39795 4–4 77 Turbine shaft end play checker (AT 1500 Series only) NR
250** 4–3 42 Valve body and governor test stand 3–13a
** Aidco, Inc.
*** No longer available.
Table 4–1. Special Tools (cont’d)
Tool No. Figure Item Description Ref. Paragraph
Container of mineral spirits for cleaning
parts
A 100 inch pound (12 Newton meter)
torque wrench
A 100 foot pound (130 Newton meter)
torque wrench
A 250 foot pound (350 Newton meter)
torque wrench
CAUTION:
Caustic cleaning compounds will damage some
transmission parts. Use only mineral spirits.
