BIBI 850-BL Use and maintenance manual Rev.00
101
TR
ACK REPLACEMENT PROCEDURE
WARNING: It is forbidden to open the reduction
gear unit for any operation other than routine
maintenance. The manufacturer declines all
liability for operations that are not part of routine
maintenance and that have caused damage to
persons or things.
Contact a specific assistance centre if
necessary.
.
Track replacement:
T
he tracks must be replaced when the tread
has worn down to 10 mm or even sooner if cuts
are noted. Proceed as described below:
1) Do not raise the machine too far from the
ground (30-40 cm are sufficient). Use the
stabilizers if the machine is equipped
with them, or use a jack as indicated in
section 3.1.
WARNING: Make sure that the machine
is in a stable position.
2) Thoroughly clean the undercarriage.
3) Remove the side clamp from the
longitudinal frame member (Figure 10).
Some models are not equipped with this
component (Figure 11).
