BIBI 850-BL Use and maintenance manual Rev.00
102
4) Loose
n the tensioning valve.
5) Only disassemble the tensioning
valve when the grease is no longer
under pressure (see Figure 12).
(See Figure 13).
Fully screw in the supplied nut
(point A) until it compresses the
spring, on both the rh and lh sides
of the chassis.
6) Retract the front wheel by pressing
on the track with your foot.
To Next Page
