Installation & Systems Manual RUBIDIUM SERIES
Page 28
Display
This module is part of the delivery and fits into the appropriate double-wide slot. There is no
initial set-up or configuration of this module possible; it is not addressable via any Rubidium
configuration tool. The serial number is located on the bottom side of the circuit board of this
module. This module has the following key features as these are usual for Rubidium Series
modules:
Failure relay, connected to the FAIL_A and FAIL_B pins of the RLC connector at the rear of
the frame.
Red LED (OPER) at the front indicates that the module is operating.
The 8-digit display (7-segment LEDs, LED colour red, 15 mm digit height) shows data received
from the TC_link interface.
Fan Module
The RUB1 Q1 frame has a fan module integrated. It is located at one side of the frame
behind the PC connector. It is replaceable.
For more information about this module please refer to chapter “The Fan Module: Fan, Frame
Address, TC_link Termination”.
For detailed information, please refer to the document “Functional Description and Specifi-
cations Q1”.
