2 The Rubidium Frames
2.1 RUBIDIUM SERIES 1
Modules belonging to RUBIDIUM SERIES 1 are denoted as RUB1 modules.
2.1.1 The “RUB1 S1” and “RUB1 T1” Chassis
The RUB1 S1 chassis was designed to house one rear loading RUB1 module in 19”/1RU
space.
RLC
PC
KEY
KEY KEY KEYID
Alperm ann+V elte
AC
RUB
1
PE:
A
C
/
DC
Adapter
Rub S1
The RUB1 T1 chassis was designed to house one rear loading RUB1 module as a tabletop
unit.
