3.14 HV: HD/SD Video Data (discont.)
The hardware consists of a digital video channel (HD/SD) with character inserter and D-
VITC/ATC time code reader and generator.
Alperman n+V elte
VIDEO IN
LOOP OUT
VIDEO OUT
Video input VIDEO IN:
Format Serial digital video, according to
ANSI/SMPTE 292M (HD) or ANSI/SMPTE 259M (SD)
Connector
BNC (IEC169-8), 75
Video time codes D-VITC (SMPTE 266M-1994), ATC (SMPTE 12M-2-2008)
Video output LOOP OUT:
Format Same as video input
Connector
BNC (IEC169-8), 75
Video output VIDEO OUT:
Format Same as video input
Connector
BNC (IEC169-8), 75
Video time codes D-VITC (SMPTE 266M-1994), ATC (SMPTE 12M-2-2008)
Others:
Operating voltage 12 - 30 VDC
Power consumption 4.5 W maximum
Weight 0.2 kg approx.
Mechanical Circuit board (W x D): 100 x 160 mm / 3.94 x 6.30 inch
Rear panel: RUB H1: 103 x 44 mm / 4.06 x 1.73 inch
RUB H3: 4HP, 3RU
