Installation & Systems Manual RUBIDIUM SERIES
Page 53
3.18 XI: Digital Video for Special Applications
The hardware of these modules comprises serial interfaces (RS232, RS422, RS485), 4 x GPIO,
and a digital video channel (SD/HD/3G).
An option has to be selected to give functionality to the module. It is not possible to order this
module without an option. A combination of options for one module is only possible if
specified.
You will find detailed information in the operating manuals mentioned below.
All manuals are available at: http://www.alpermann-velte.com/serv_e/bal_e/bal_e.html
.
Option Description
-C: Clip length inserter The option has been developed to let the module operate with an
automation system. While the automation system runs the playlist a
simple command can be transmitted to transfer the clip length to
the module. The module starts a DOWN counter, converts this time
into LTC format, and visibly inserts the time on a video window.
Two independent DOWN counters are available.
Operating manual: “AI / DI / XI Modules + Option C“.
-D: Daytime inserter An external reference (GPS, DCF77) delivers a pulse per second
(PPS) and time & date via serial interface. The module decodes
these data, calculates the local time, and visibly inserts a precise
time (HH:MM:SS:1/100) in a video window. Different formats of
time and date representation are selectable.
Operating manual: “AI / DI / XI Modules + Option D“.
-V: VPS decoder VPS: Video Program System. A module with this option decodes
these data out of an ancillary data packet according to SMPTE
2031 in conjunction with ETSI EN 301 775. The decoded data can
visibly be displayed on a video window. GPIO signal outputs are
available signalling the state of selected bits.
This option may be combined with option W.
Operating manual: “AI / DI / XI Modules + Option V“.
-W: WSS decoder WSS: Wide Screen Signalling. A module with this option decodes
these data out of an ancillary data packet according to SMPTE
2031 in conjunction with ETSI EN 301 775. The decoded data can
visibly be displayed on a video window. GPIO signal outputs are
available signalling the state of selected bits.
This option may be combined with option V.
Operating manual: “AI / DI / XI Modules + Option W“.
