CS1100 SPARE PARTS LIST
ITEM
PART NO.
DESCRIPTION
1
SPK/LS/0004/A
MOTOR DRIVE PC BOARD ASSEMBLY
2
SPK/CS/0005
PROCESSOR PC BOARD ASSEMBLY
3
SPK/LS/0006/B
MOTOR ASSEMBLY WITH ENCODER
4
SPK/LS/0007
CROSSHEAD LIMIT ACTUATOR ARM
5
SPK/LS/0008
LIMIT STOP SCREW ASSEMBLY
6
SPK/CS/0009
CONTROL CONSOLE TABLET
7
SPK/CS/0010
BASE PLATE ASSEMBLY
8
SPK/LS/0011/B
FUSES - (1 PAIR)
9
SPK/CS/0012
CF CARD - PROGRAMMED
10
SPK/LS/0013/B
TRANSFORMER ASSEMBLY
11
SPK/LS/0014/C
POWER ENTRY MODULE ASSEMBLY 230VAC
11
SPK/LS/0014/D
POWER ENTRY MODULE ASSEMBLY 115VAC
12
SPK/LS/0015
E-STOP SWITCH ASSEMBLY
13
SPK/LS/0016
SAFE-LINE SWITCH ASSEMBLY
14
SPK/LS/0017
LOAD CELL LOOM ASSEMBLY
15
SPK/CS/0018
CONTROL CONSOLE USB CABLE
16
SPK/LS/0019
ENCODER LOOM ASSEMBLY
17
SPK/LS/0020
SAFE-LINE LOOM ASSEMBLY
18
SPK/LS/0021
INTERNAL LOAD CELL LOOM ASSEMBLY
19
SPK/CS/0022
MOUNT, CONTROL CONSOLE
20
SPK/LS/0023
LOOM ASSEMBLY, POWER SUPPLY TO PROCESSOR PCB
21
SPK/LS/0024/B
MOTOR PULLEY
22
SPK/LS/0025/B
LEADSCREW PULLEY
23
SPK/LS/0026
LOOM MOTOR DRIVE TO PROCESSOR
24
SPK/LS/0027/B
LIMIT ROD ASSEMBLY 800mm TRAVEL
25
SPK/LS/0028
LOWER LIMIT SWITCH ASSEMBLY
26
SPK/LS/0029/B
LOWER BEARING ASSEMBLY
27
SPK/LS/0030
UPPER BEARING
28
SPK/LS/0031/C
LEADSCREW ASSEMBLY
29
SPK/LS/0032
LOOM - LIMIT SWITCHES TO PWM DRIVE
30
SPK/CS/0050
SPACER KIT - MACHINE BENCH MOUNTING
132 CS User Manual
