the amount of memory required. If the “Auto-archive after 500 test runs” box is not checked
the CS Series console will automatically archive the data after 500 test runs to the default
path C:\Documents and Settings\MyUser\ folder.
If the specified drive for the data archive is not available at the time of the archive the test
data will go to the default location C:\Documents and Settings\MyUser folder.
9.15
DISPLAYING THE TEST GRAPH
SCREEN
After the Archive and Export Settings have been set, press on the "FINISH" button at the
bottom of the screen to display the "TEST GRAPH" screen.
This screen has a title showing the previously entered test name.
Please refer to section 10 for details regarding test samples.
76 CS User Manual
