3.0
INITIAL
CONFIGURATION
3.1 GENERAL
The control console uses Windows Embedded Standard for the Operating System together
with a dedicated force tester program. Both items need to be configured before the system
is fully operational and all features become available.
NOTE
An external PC keyboard and a touch screen stylus are required to fully
configure the system. Connect the PC keyboard into the unused USB
connector or the PS2 connector on the right hand side of the control
console, depending upon the keyboard connector.
Alternatively, a USB hub can be used to connect a USB mouse and a USB
keyboard, in which case a touch screen stylus is not required.
3.2
INITIAL
LOG-IN
Switch the
Force Tester
on and wait for the "LOGIN" screen to appear.
Using a stylus, click on the "LOGIN" button to display the "HOME" screen (Do not click on
Username or Password).
18 CS User Manual
