127139 13 2014-07-30 111

7.3 Maintenance of STS-reference sensor

Use the configuration software CON050 supplied with the RTC to

update calibration information in the intelligent reference sensor.

Read the STS- and CON050 manuals for instruction about calibration

and up-/download procedure.

The following information in the sensor is used by the RTC and must

be filled in correctly:

 Serial number

 Model number

 Sensor type

 Temperature range Min/Max

 Electrical output Min/Max

 RTD type (CvD or ITS-90)

 Calibration date

 Calibration initials

 Calibration period

 R0, A, B and C (RTD type = CvD)

 RTPW, A(LR), B(LR)C(LR)/C1(LR), C2(LR), C3(LR), C4(LR),

C5(LR) A(HR), B(HR), C(HR), D(HR) and W(HR) (RTD type = ITS-

90)

All other data are not used by the RTC.

Ametek JOFRA RTC-156 B User Manual
