6.0 Replacing the main fuses
Warning
The calibrator must be switched off before any attempt to
service the instrument is made. There are no user
serviceable parts inside the calibrator.
The fuse box must not be removed from the power
control switch until the mains cable has been
disconnected.
The two main fuses must have the specified current and
voltage rating and be of the specified type. The use of
makeshift fuses and the short-circuiting of fuse holders
are prohibited and may cause a hazard.
Fig. 15
Locate the main fuses in the fuse box in the power control
switch.
Open the lid of the fuse box using a screwdriver.
Remove the fuse box.
2
4
3
1
4
