34 2014-07-30 127139 13
Tables of recommended oil level @23°C well temperature
RTC-250 A/B/C RTC-158 A/B/C
For recommended
50 cSt oil
For recommended
10 cSt oil
0°C - 50°C
100%
-20°C - 50°C 100%
50°C - 100°C 95%
50°C - 100°C 95%
100°C - 150°C 90%
100°C - 120°C 90%
150°C - 200°C 85%
120°C - 155°C 85%
200°C - 250°C 80%
For the best result, the oil should be in good condition and free of
foreign objects. If water is accumulated in the oil due to melted ice
crystals – the oil must be dried out, by heating it up.
Warning
Do not handle hot fluid.
If the fluid is heated beyond the flash point, it may
constitute a fire hazard.
If the fluid has caught fire, switch off the main power to prevent further
heating of the fluid. Flames are best extinguished by cowering the well
with a non-flammable lid.
Warning
Do not under any circumstances pour water on burning oil. It
might cause a dangerous steam explosion.
3.3.3 Handling of lids
It is strongly recommended to leave the lid on during calibration.
Calibration without the lid may affect the temperature stability and
homogeneity.
