7.4 Maintenance of DLC-sensor
Use the configuration software CON050 supplied with the RTC to
update calibration information in the intelligent reference sensor.
Read the DLC- and CON050 manuals for instruction about calibration
and up-/download procedure.
The following information in the sensor is used by the RTC and must
be filled in correctly:
 Serial number
 Model number
 Sensor type
 Temperature range Min/Max
 Electrical output Min/Max
 TC-type (DLC-155/158/159/250 = T, DLC-700 = N)
 CJC (Must be set to "No compensation")
 Calibration date
 Calibration initials
 Calibration period
 Correction coefficients A, B and C
All other data are not used by the RTC.
