80 2014-07-30 127139 13
4.10.3 Setting the parameters for DLC– dynamic load
compensation (B and C versions only)
The DLC value on the main screen will be read from the
Intelligent Load Sensor as soon as it is connected to the
DLC INPUT on the front panel (see section 4.2 fig. 6). The
calibrator automatically reads the calibration data and serial
number of the Sensor.
However if the Dynamic Load Compensation shall be active,
it must be enabled.
Use load compensation:
The active “DLC” function is indicated with the symbol at
the DLC reading in the main display.
Note…
always use external reference sensor when calibrating with
the DLC-function activated for specified accuracy.
Press to accept the new setting(s) and return to the
Sensor setup menu or continue to edit the reference sensor
parameters or the Sensor under test parameters.
4.10.4 Setting the parameters for SUT– Sensor under test (B
versions only)
Sensor type:
Choose between :
thermocouple sensors (V)
voltage sensors (V)
current (ma) sensors
RTD sensors (resistance temp. detector ())
None (no sensor connected)
Select a sensor.
The selected sensor and its list of parameters are now
displayed. The various settings can be edited as described in
the following :
