3.2.3 Inserting the sensors
Before inserting the sensors and switching on the calibrator, please
note the following important warning:
Warning
Never use heat transfer fluids such as silicone, oil, paste,
etc. in the dry-block calibrators. These fluids may
penetrate the calibrator and cause electrical hazard,
damage or create poisonous fumes.
Insert the sensors as shown in fig. 2.
Fig. 2
The DLC sensor must be placed in the hole that is intended for the
DLC sensor. Standard insertion tubes from AMETEK Denmark are
Reference sensor
(if available)
Sensor under test
DLC sensor
(if available)
