40 2014-07-30 127139 13
Pos. Description
6
24V supply for active mA input (B-version)
7
Passive mA input (B-version)
8
Voltage input (B-version)
9
Connection to chassis (earth/ground) (B-version)
10
TC connection for thermocouples (B-version)
11
Input for RTD sensor (2, 3 or 4 wire) (B-version)
One of the inputs either pos. 7, 8, 10 or 11
can be selected displaying
the “SENSOR” temperature in the Setup and pos. 3 can be displayed
as “TRUE” temperature.
Note: Only the sensor type, which is to be tested, should be connected
to the input panel.
