Voltage(V) and temperature(T) span:
(using voltage)
The minimum and the maximum of the voltage and the
corresponding temperature span can be set here.
Use the NUMERIC keys to set the value of the voltage
and/or the temperature.
Current(C) and temperature(T) span:
(using current)
The minimum and the maximum of the current and the
corresponding temperature span can be set here.
Use the NUMERIC keys to set the value of the current
and/or the temperature.
Number of wires:
(using RTD)
The number of wires used for the sensor under test can be
selected here.
Choose between 2, 3 or 4 wires.
Use stability criteria:
(using thermocouple, voltage, current and RTD)
Beside the stability check on the Reference sensor, it is also
possible to ensure that the Sensor Under Test (SENSOR) is
stable before the temperature is indicated as stable.
“yes” – Stability will be checked on both Reference
sensor (TRUE) temperature and Sensor Under Test
(SENSOR) temperature.
“no” – Stability will be checked on Reference sensor
(TRUE) temperature only.
Stability tolerance:
(using thermocouple, voltage, current and RTD)
Enter the Stability tolerance (temperature) by pressing the
NUMERIC keys.
