Installation, Operation and Maintenance Manual
OXYvisor Optical Oxygen Analyzer
2.1 OXYvisor - BOA Oxygen Analyzer Specicaons

OXYvisor Oxygen Analyzer Specications
Power Supply - Selectable as AC or DC via Product Selection Nomenclature
AC Power 85-264 VAC, 47-63 Hz, 6W (AC, “4-wire,” line powered analyzer)
DC Power 24 V DC +/-10% 5W (Class 2 / LPS source) (DC, “4-wire,” line powered analyzer. Not a 2-wire loop powered transmitter)
Environmental
Operating Temperature -20 to +55ºC (-4 to 131ºF)
Storage Temperature -20 to +65ºC (-4 to 149ºF)
Max. Operating Relative Humidity 95%, non-condensing
Max Altitude Maximum altitude up to 2,000 meters (6,561 ft)
IEC IEC Installation Category II and Pollution Degree 2
Physical
Main
Enclosure and
Junction Box
Ratings IP66 and NEMA 4x, protected against dust and high pressure water ingress. Corrosion resistant.
Material Type Aluminum pressure die-casting with yellow chromating and chemically resistant paint
Conduit Entries Main enclosure = QTY 4, junction box = QTY 2, 3/4” FNPT or M25 x 1.5 6H conduit entries
O-Ring Seals Silicone VMQ rubber
Dimensions H x W x D (combined) 12.0 x 5.5 x 11.0 inches (30.5 x 14.0 x 28 cm)
Weight (total/combined) 13.7 lb (6.2 kg)
Liquid Crystal Display Viewing = 79 (W) x 40 (H) mm, 240 x 128 dots, FSTN / Positive / Transective
HMI Touch-Keys (through-the-glass) (4) proximity switches, infrared contacts for interactive user interface at HMI
Input Information
Sensor Inputs
Optical O
2
(1) O
2
optical input BOS1, BOS2 or BOS3 sensor (SMA connector)
RTD - Temp (1) Pt100 or Pt1000 4-wire RTD Inputs (isolated)
Analog Input (1) 4-20 mA input (24 Vdc active from OXYvisor) - User congurable for Temperature or Pressure transmitter
Pressure Sensor (1) On-board integrated pressure sensor measures and compensates for ambient pressure conditions
Digital Inputs (2) optically isolated inputs, 5 Vdc powered, remote initiation of automatic calibration and live validation gas
Output Information
Analog Outputs (2) Programmable current outputs with galvanic isolation, 4 to 20 mA (Active), Linear or Bi-Linear, 24 Vdc
Digital Outputs (Alarm/Relays) (4) Programmable relays, optically isolated, passive, 24Vdc, 0.05A pilot duty, 0.45 A general use/ resistive load.
Digital Communication (1) Modbus RTU serial protocol RS485 - Two way Communication
User Adjustable Options
Oxygen Units Gas Phase: %O
2
, ppm, hPa Liquid Phase: ppm, ppb, hPa
Temperature Units Fahrenheit or Celsius
Pressure Units mbar, inches H
2
O, Bar and PSI (absolute pressure)
Advanced Features
Automatic Calibration (AutoCal) AutoCal logic controls 3 relays, user programmable with time based schedule or user initiated (requires AutoCal panel)
Remote Validation (Test Gas Insert) Test gas insert allows for remote or local validation with Test Gas (requires AutoCal panel)
Auto-Sample Rate Minimizes drift between calibrations, increases sensor lifetime without decreasing performance when needed
Temperature Compensation Automatic Temperature compensation to account for sensor output & used for DO calculation
Pressure Compensation Pressure compensates/corrects for concentration calculations due to ambient or process pressure changes
Analog Input Calibration Allows for correction/matching of Analog Input, either remote temperature or pressure transmitter
Data & Error Logging Options Last 10 error messages and calibrations time/date stamped (.pdf le), USB data trend storage (.csv le)
OXYvisor PC Software Conguration, programming, set-up, measurement, diagnostics, and trending (requires RS485 to USB cable)
󰀚
Section 2
Technical Product Specication
