PC Congurator Software | A-7
You can direct process readings to any of the three analog output ports.
Each of the outputs can be configured for:
• Function
• Mode
• Span and Zero Ranges
• Track or Hold while calibrating
Function %O
2
Cell mV
Combustibles
Methane
Mode 0-20 mA
4-20 mA
Namur*
Span Enter reading for 20 mA
% for O
2
& methane
ppm for combustibles
mV for cell millivolts
Zero Enter reading for 0/4 mA
% for O
2
& methane
ppm for combustibles
mV for cell millivolts
Track/Hold during Cal** Track during cal
Hold during cal
** Define the signals to send to the selected analog output port during a calibra-
tion. You have the option to either hold the last process reading or track calibration
readings.
* The Namur Standard is implemented as follows:
4-20 mA Signal Analyzer Condition
0 mA Analyzer without power or completely failed
3.5 mA Critical Alarm - analyzer reading unusable
3.8 mA Reading Under Range (Example - user sets range to
2-10%. Current reading is 1.9%)
4 to 20 mA Normal Operation
20.5 mA Reading Over Range (Example - range is 0-10%. Current
reading is 12%)
When you have entered the information for each function, click the SET
button at the bottom of the screen to apply the values.
