A-28 | Thermox WDG-V Series Analyzers
If you have already entered your calibration gas values under the
Configuration_Cal Gas Values tab, they will be visible in the fields.
Any changes that you make to these values will be reflected in the Cal
Gas Values menu as well.
6. When you are satisfied with your values, Click on the START button
to start the automatic calibration. The screen displays the Gas Value,
Cal Gas and Time Remaining. To abort the calibration, click on the
Abort button.
Figure28.Calibration_O
2
Span Gas Auto Calibration screen.
7. The screens will advance upon completion of each calibration to the
next gas to be calibrated.
Figure29.Calibration_ZeroGasAutoCalibrationscreen.
8. The screen displays the Gas Value, Cal Gas and Time Remaining. The
process will advance to the next gas to be calibrated. To abort the cali-
bration, click on the Abort button.
