Maintenance 109
1201281 A | 24.07.2013
9.13.2 Roller drum scraper
Roller drum
scraper
1 Tension the scrapers lightly by hand.
Fig. 9-23 Roller drum scraper
Scraper for
pneumatic wheels
1 Adjust the scrapers with a clearance of 3-5mm.
1.1 The anti-adhesive must not be scraped off.
Fig. 9-24 Clearance of scraper to pneumatic wheels
9.13.3 Tire pressure
1 Check the tire pressure on the pneumatic wheel axle.
2a = 1bar: OK.
2b < 1bar: Increase pressure by pumping in some air.
2c > 1bar: Reduce pressure by letting air out.
