Ammann ARX 16 - Work Gear; Transport Gear

62 ARX 1
1201281 A | 24.07.2013
Driving
backwards
1 Pull the operating lever back slowly.
The roller moves backward.
Slowing down 1 Slowly pull the operating lever into the neutral position.
The roller is automatically hydrostatically braked.
NOTE If the operating lever is released it does not automatically return to the neutral
position. The lever remains at its current position.
NOTE If the operating lever is jerked over the neutral position, e.g. as a result of an
emergency situation, the machine will stop.
7.6 Work gear / transport gear
The roller is equipped with two gears.
1 Turn the switch:
2a toward the left: the hydraulic system is switched to the "transport gear" drive
position.
The vibration cannot be switched on now. The roller drives at a high
speed.
2b toward the right: the hydraulic system is switched to the "work gear" drive
position. The vibration can now be switched on as well. The roller drives at a
low speed.
