98 ARX 1
1201281 A | 24.07.2013
Fig. 9-5 Diesel drain
9.8.4 Cleaning the fuel tank
Over time, condensation water gathers in the fuel tank. It must be drained once a
year.
1 Loosen the screw plug (1) beneath the roller using an open-ended wrench
(size 19).
2 Place a container under the drain tap.
3 Allow about 1/2 liter of fluid to drain.
First, the water which has collected on the bottom of the tank will run out.
4 Install the screw plug (1).
4.1 Secure the screw connections with Ergo 4207 and tighten by hand, not
with torque. Observe the table Tightening torque: Drain cock, Page 119
9.8.5 Fuel filter element
Fig. 9-6 Fuel filter
Replace fuel filter element (1) according to the maintenance plan.
1 Close stop cock (2).
1.1 Move to OFF.
2 Unscrew the filter housing (3).
