Ammann ARX 16 - Specifications

1201281 A | 24.07.2013
2.2.2 Specifications
Tab. 2-4 ARX 1 performance Characteristics
ARX 12 ARX 16 ARX 16 K ARX 20
Operating weight of EN 500-1+A1
(CECE) (kg)
1475 1520 1460 1570
Maximum weight (kg) 1700 1700 1700 1700
Static linear load (kg / cm) 9 8.4 8.4 7.9
Wheel load (kg) - - 183 -
Turning radius inner (mm) 2165 2125 2125 2075
Vibration Amplitude (mm) 0.5 0.5 0.5 0.45
Centrifugal force (kN) 23 23 23 24
Gradient in % with / without vibration 30 / 40 30 / 40 30 / 40 30 / 40
Engine
Engines complies with emission
regulations
YANMAR 3TNV76 / EPA 4
U.S. EPA Tier 4 Interim
Performance according to ISO 3046-1 15,1 kW / 20,2 HP
Nominal speed 2 400 min
-1
Working speed 0- 8 km /h
Angle of steering / Oscillation angle +/- 31° / +/- 5°
Frequency Vibration I/II 58 Hz / 66 Hz
Fill levels
Tab. 2-5 ARX 1 fill levels
Container Contents
Water tank capacity 110 l
Hydraulic oil tank 16 l
Diesel tank 26 l
Anti-adhesive tank 10 l
22 ARX 1
