6.1 Commissioning
NOTE Familiarize yourself with the manual before commissioning.
In order to begin operating the roller (driving), the following conditions must be
fulfilled:
● Joint protection is opened.
● Motor is started.
● Seat contact is closed.
● Operating lever is in the neutral position.
● Parking brake is not activated.
In order to be able to activate the vibration, the work gear must also be activated.
6.1.1 Roller with pneumatic wheel (combined roller)
● If using a combined roller, you must check tire pressure and adjust as required.
The ex works pressure is set to 1bar.
● Tire pressure must be adjusted to suit the compaction condition of the ground:
NOTE The tires must be replaced if the fabric is visible on the tire surface.
Tire pressure OK
Tire pressure too low
Tire pressure too high
