Options 73
1201281 A | 24.07.2013
8.3 Brake light
The brake lights light up:
● When the ignition is switched on.
● When the seat contact is activated.
● When the operating lever is in the neutral position.
The brake lights do not light up:
● When the operating lever is actuated forwards/backwards away from the neutral
position.
8.4 Indicators
Switching the blinker on and off:
1 Turn the switch:
2a to position 1: Left blinker activated.
2b to position 2: Right blinker activated.
8.5 Rear work light and revolving warning light
Switching the work light and the revolving warning light on and off:
1 Turn the switch:
2a to position 0: Both the work light and the revolving warning light are switched
off.
2b to position 1: The rear revolving warning light is switched on.
2c to position 2: Both the rear work light and the revolving warning light are
switched on.
NOTE If the roller is no longer fitted with a revolving warning light, only the work light
is lit.
8.6 Work light
Switching the working light on the ROPS on and off:
1 Turn the switch:
2a To position 0: The working lights are switched off.
2b to position 1: Both the rear work light (if present) and the working light are
switched on.
