78 ARX 1
1201281 A | 24.07.2013
NOTE NOTE
The Velcro straps are used to secure the padlocks in order to prevent them
from producing noise caused by vibration.
Fig. 8-8 Securing the padlocks
8.11 Locking water tank
Advantages of a locked water tank:
● Locking serves to prevent loss of the cover.
● Prevent vandalism to the water tank by third parties.
NOTE The ignition key is used to lock and unlock the water tank cover.
Fig. 8-9 Water tank cover
8.12 Reverse alarm
The reverse alarm is active as soon as the roller drives backward. The alarm stays
on until the roller starts to drive forward or comes to a standstill.
97dB +/- 4dB to SAE J 994, Oct. 03
