Ammann ARX 16 - Key for ARX 1 Wiring Diagram

150 ARX 1
1201281 A | 24.07.2013
14.1.1 Key for ARX 1 wiring diagram
Element Description
A1 Fuel level display, diesel tank
A2 Voltage display
B1 Horn
B11 Reverse alarm
B12 Warning buzzer, flow divider
B13 Warning buzzer, seat contact delay
E1 Front right dipped light
E2 Front left dipped light
E3 Work light rear
E11 Front right parking light
E12 Front right position light
E13 Front left parking light
E14 Front left position light
E15 Rear right parking light
E16 Rear left parking light
E17 Front right indicator
E18 Front left indicator
E19 Rear right indicator
E20 Rear left indicator
E21 Revolving warning light
E22 License plate illumination
E23 Work light ROPS
E24 Work light ROPS
E25 Right brake-light
E26 Left brake-light
F1 Fuse, hazard flasher
F2 Fuse, parking light 1
F3 Fuse, parking light 2
F4 Dipped light fuse
F5 Fuse, revolving warning light, work light
F6 Fuse, horn
F7 Fuse, display unit, reverse alarm, blinker
F8 Fuse, Seat heating
F9 Fuse, controller, supply
A3 * Monitoring device
