Appendix 151
1201281 A | 24.07.2013
F10 Fuse, controller, outputs
F11 Fuse, sprinkler
F12 Fuse, flow divider, edge cutter
F13 Fuse - vibration
F14 Fuse, controller, inputs
F15 Fuse, hydraulic oil cooler
F16 Fuse, reserve
F21 Fuse, starter
F22 Fuse, diesel pump
F23 Fuse, reserve
F24 Fuse, reserve
G1 Alternator
G2 Battery
H1 Warning lamp, error
H2 Control lamp, charging control
H3 Warning lamp - engine oil pressure
H4 Warning lamp - coolant temperature
H5 Warning lamp, hydraulic oil temperature
H6 Warning lamp, emergency stop
H7 Warning lamp, diesel reserve
H8 Control lamp, pre-heating
H9 Control lamp, brake pressure
H10 Control lamp, parking lights
H11 Control lamp, dipped lights
H12 Control lamp, blinker
K1 Relay, starting interlock
K2 Timer relay
K3 Relay, pull-in solenoid
K4 Relay, vibration
K5 Relay, hydraulic oil cooler
K6 Relay, sprinkler
K7 ** Relay, starting interlock
K11 Relay, blinker
K12 Relay, anti-adhesive sprinkler
K13 Relay, edge cutter
Element Description
F25 ** Fus
e, altitude solenoid power supply
F26 ** Fuse, altitude s
olenoid unit power supply
