Operation 67
1201281 A | 24.07.2013
7.13 Simple/double vibration
NOTE Damage to material due to harsh vibration movement.
• Never use vibration while idling!
• Never use vibration while at a standstill!
• Only switch vibration on if the speed adjusting lever is set to an operating
speed.
7.13.1 Switching vibration on/off
Presetting 1 Turn the switch:
2a toward the left:The roller only vibrates at the front.
2b toward right: The roller vibrates both at the front and the rear.
NOTE When switching from double to single vibration, there is a brief interruption of
the vibration.
Switching on / off 1 Press the top button briefly on the operating lever (1).
Vibration switches on.
2 Press the top button again on the operating lever (1).
Vibration switches off.
7.14 Vibration automation
In automatic mode vibration is switched on at speeds greater than 1-2 km/h and off
at speeds less than 1-2 km/h.
Item 0 Off
Item 1 Interval sprinkler
WARNING
Danger to life through slipping or caving in of the roller!
• Do not use vibration on steep embankments or at steep angles!
• Do not vibrate inside buildings and on unstable ground!
