Ammann ARX 16 - Drain Cock; Threaded Bolt for ROPS Joint; Threaded Adapters; Metric Threads; Tightening Torque: Drivers Seat, Seat Belt Fastening Screws

Maintenance 119
1201281 A | 24.07.2013
Tab. 9-9 Tightening torque: Driver’s seat, seat belt fastening screws
9.17.2 Drain cock
Tab. 9-10 Tightening torque: Drain cock
9.17.3 Threaded bolt for ROPS joint
Grease with Never-Seez anti-seize lubricating compound, for example
Tab. 9-11 Tightening torque: Threaded bolt for ROPS joint
9.17.4 Threaded adapters / Metric threads
Tab. 9-12 Tightening torques for threaded adapters / metric threads
AF size
hex key
Screw
diameter
Steel quality
Tightening torque in
Nm
5/8“ UNF 7/16” 8.8 45
Drain cock
Diesel tank Secure the screw connections with ERGO 4207 and tighten by
hand, not with torque.
Hydraulic tank Secure the screw connections with ERGO 4207 and tighten by
hand, not with torque.
Screw
diameter
Steel quality Tightening torque in Nm
M18 S355 147 Nm (30 kg on 50 cm lever)
Thread size Cutting ring Soft seat ring Nominal joint size
M10x1.0 18 Nm 18 Nm 6 L
M12x1.5 25 Nm 25 Nm 8 L
M14x1.5 45 Nm 45 Nm 10 L
M16x1.5 55 Nm 55 Nm 12 L
M18x1.5 70 Nm 70 Nm 15 L
M22x1.5 125 Nm 125 Nm 18 L
M26x1.5 180 Nm 180 Nm 22 L
M33x2.0 310 Nm 310 Nm 28 L
M12x1.5 35 Nm 40 Nm 6 S
M14x1.5 55 Nm 40 Nm 8 S
M16x1.5 70 Nm 70 Nm 10 S
