2.1 Identification of the roller
2.1.1 Machine types
The data given below serve to identify the models. The machine models differ only
in terms of weight and the width of the roller drum. The combined roller has a
pneumatic wheel axle instead of the smooth back roller drum.
ARX 12
ARX 16
ARX 20
Tab. 2-1 Roller with roller drum
ARX 16 K
Tab. 2-2 Roller with pneumatic wheel (combined roller)
Model Roller drum width Weight
ARX 12 820 mm 1475 kg
ARX 16 900 mm 1520 kg
ARX 20 1000 mm 1570 kg
Model Roller drum width Weight
ARX 16K 900 mm 1460kg
