82 ARX 1
1201281 A | 24.07.2013
8.15.3 Specifications
Tab. 8-2 Temperature sensor specifications
8.16 Anti-adhesive
Anti-adhesive is a water-soluble specialized liquid for combined rollers. The anti-
adhesive ensures effective separation between the pneumatic surfaces and the
bitumen surface.
The anti-adhesive tank filler neck is located on the left-hand side of the driver’s
position under the cover in the footplate.
Anti-adhesive reservoir volume: 12.5l
Fig. 8-15 Anti-adhesive reservoir filler neck
8.16.1 Switching on anti-adhesive
1 Press the bottom button (1) on the operating lever.
Anti-adhesive is admixed until you release the button.
NOTE The water sprinkler for the roller drum is controlled via the instrument panel.
Model Infrared sensor
Measurement range 0-500°C
Set emissivity 0.95
Diameter of the measuring spot about 150mm (half the amount of the distance
to the ground)
