64 ARX 1
1201281 A | 24.07.2013
NOTE The seat switch can be opened when:
• the driver leans out to the side and no longer sits on the seat with his full
weight.
• the driver is too light. In this case, adjust the seat for the driver using the
weight adjustment.
7.9.2 Closing the seat switch
1 Put the operating lever into the neutral position.
1.1 You can leave the speed adjusting lever in its previous position.
2 Start the roller by moving the operating lever.
NOTE If the driver sits down again within the delay period, the roller continues to
drive normally.
7.10 Emergency stop
If you get into an emergency situation requiring an immediate standstill of the roller,
then press the emergency stop on the instrument panel.
7.10.1 Initiating an emergency stop
Emergency stop
1 Press the emergency-stop button.
The roller comes to a standstill immediately. The engine shuts down immediately and
automatically. The brakes are activated.
NOTE Only press the emergency stop in an emergency.
7.10.2 Releasing the emergency stop
1 Put the operating lever into the neutral position.
2 Move the speed adjusting lever all the way back.
3 Now turn the emergency stop button slightly in the direction of the arrow until
its clicks out.
The roller is now ready for operation.
NOTE Release the emergency stop button by pulling upwards in the "pull-push"
version. The direction arrows are missing from this button.
