96 ARX 1
1201281 A | 24.07.2013
9.8 Fuel (diesel)
9.8.1 Checking fuel level
Diesel control lamp
After the control lamp on the instrument panel lights up for the first time, the fuel in
the tank will last at least ½ h.
9.8.2 Refueling
1 Fill the fuel tank with diesel fuel up to the lower edge of the filler neck.
1a Every day before beginning work,
1b or as soon as the warning lamp lights up.
The tank holds 26liters of diesel fuel.
Fig. 9-4 Diesel fuel filler neck
WARNING
Risk of burning and injury when handling parts in the engine
compartment!
• Switch the diesel engine off when performing any inspection
work. The locking brake is active when the diesel engine is
switched off.
