Operating and display elements 47
1201281 A | 24.07.2013
Hydraulic oil
temperature
The Hydraulic oil temperature control lamp lights as soon as the oil temperature
exceeds 85°C. As soon as the temperature exceeds 95 °C, error F32 appears as
well. In this condition, the machine can only be driven at 1km/h and the vibration can
no longer be switched on. The machine may only be driven normally again after the
temperature has gone below 95 °C.
1 Check the function of the hydraulic oil radiator fan.
2 Clean heavy soiling from the radiator body.
Emergency stop If the emergency-stop control lamp lights up while the ignition is on, observe the
following:
1 Release the Emergency Stop button by turning it clockwise (red mushroom
button on the instrument panel).
2 Put the operating lever into neutral position.
3 Sit on the driver’s seat.
4* If the control lamp still continues to be lit: Call a specialist to remedy the
problem.
Diesel reserve After the Diesel reserve control lamp lights up for the first time, the fuel in the tank
will last at least ½h.
1 Top up diesel fuel.
The tank holds 43 liters of diesel fuel.
Pre-heating The pre-heating time lasts about 15s. The pre-heating indicator lamp extinguishes
when the engine is started.
Brake pressure As long as the control lamp for brake pressure is lit, the brake release and supply
pressure of the hydraulic system is not sufficient. As long as this control lamp is
lit, the machine cannot be driven.
1 Check whether the seat contact switch is closed.
2 Check whether errors are displayed.
3* The seat contact switch is closed and the control lamp is still lit: Call a
specialist to remedy the problem.
