1.3. Technical Data
ASC 110 Cummins Tier 3
D HD HT PD HDPD HTPD
Engine
Manufacturer - Cummins Cummins Cummins Cummins Cummins Cummins
Type - QSB4.5-C160 QSB4.5-C160 QSB4.5-C160 QSB4.5-C160 QSB4.5-C160 QSB4.5-C160
Power according to
DIN 6271
kW (HP) 119 (160) 119 (160) 119 (160) 119 (160) 119 (160) 119 (160)
Power according to
ISO 3046/1
kW (HP) 119 (160) 119 (160) 119 (160) 119 (160) 119 (160) 119 (160)
Number of cylinders - 4 4 4 4 4 4
Cylinder capacity cm
3
(cu in) 4500 (275) 4500 (275) 4500 (275) 4500 (275) 4500 (275) 4500 (275)
Nominal speed min
-1
(RPM) 2200 2200 2200 2200 2200 2200
Maximum torque Nm/rpm 624/1500 624/1500 624/1500 624/1500 624/1500 624/1500
Routine operation
fuel consumption
l/h
(gal US/h)
11,8 (3,1) 11,8 (3,1) 11,8 (3,1) 11,8 (3,1) 11,8 (3,1) 11,8 (3,1)
Engines complies
with emission regu-
lations
- 97/68/EU Level 3, EPA/CARB 40 CFR Part 89 Tier 3
Cooling system of
engine
- Liquid Liquid Liquid Liquid Liquid Liquid
Axle
Maximum tyre
pressure
MPa (PSI) 0,160 (23,2) 0,160 (23,2) 0,160 (23,2) 0,160 (23,2) 0,160 (23,2) 0,160 (23,2)
Pattern of tyres -
UK-5
Diamond
UK-5
Diamond
UK-5
Diamond
TR-1 Tractor TR-1 Tractor TR-1 Tractor
Size of tyres - 23,1x26´´ 23,1x26´´ 23,1x26´´ 23,1x26´´ 23,1x26´´ 23,1x26´´
Type of tyres - Tubeless Tubeless Tubeless Tubeless Tubeless Tubeless
Number of pads
(only PD version)
- 140 140 140
Pad contact surface
(only PD version)
cm
2
(sq in) 120 (18,6) 120 (18,6) 120 (18,6)
Pad height (only PD
version)
mm (in) 100 (3,93) 100 (3,93) 100 (3,93)
Brakes
Operating - Hydrostatic Hydrostatic Hydrostatic Hydrostatic Hydrostatic Hydrostatic
Parking -
Multiple-disc
spring brake
Multiple-disc
spring brake
Multiple-disc
spring brake
Multiple-disc
spring brake
Multiple-disc
spring brake
Multiple-disc
spring brake
Emergency -
Multiple-disc
spring brake
Multiple-disc
spring brake
Multiple-disc
spring brake
Multiple-disc
spring brake
Multiple-disc
spring brake
Multiple-disc
spring brake
Vibration
Small amplitude mm (in) 1,15 (0,045) 1,15 (0,045) 1,15 (0,045) 1,1 (0,043) 1,1 (0,043) 1,1 (0,043)
Large amplitude mm (in) 1,85 (0,073) 1,85 (0,073) 1,85 (0,073) 2,0 (0,078) 2,0 (0,078) 2,0 (0,078)
Low frequency Hz (VPM)
32 (1920) 32 (1920) 32 (1920) 31 (1860) 31 (1860) 31 (1860)
High frequency Hz (VPM) 35 (2100) 35 (2100) 35 (2100) 35 (2100) 35 (2100) 35 (2100)
Low centrifugal force kN 206 206 206 220 220 220
High centrifugal
force
kN 277 277 277 277 277 277
Type of drive - Hydrostatic Hydrostatic Hydrostatic Hydrostatic Hydrostatic Hydrostatic
