20%
FUEL LEVEL
100
ENG HRS
28°C
COOL TEMP
0 RPM
ENG RPM
396313
100
220
180
250
J1939
°C
°F
80
40
100
120
396061
0
I
II
2.7. Machine control and use
Turn key in ignition box 1 to position ”l” - the pilot lamps for •
brake, recharging, neutral, engine glowing (as per ambient
temperature) will light. ROPS2D indicator lamp will light up
shortly along with acoustic alarm.
The display will show logo and then 4 quadrants with para-
•
meters set.
Note
The display has been set by Manufacturer, it is possible to
change it to a single parameter display, refer to par. 2.6.1.
Glowing indicator lamp goes o, please switch to position
•
“II” to start the engine and (hold key in ”ll” position only until
engine is started).
Do NOT start for no longer than 30 sec.
Repeat starting only after 2 minutes.
Repeat starting max 3x, then track a fail-
ure within fuel system. Absence of smoke
in exhaust will signal a defect within fuel
supply to the engine.
When started, please check recharging
function - indicator lamp must go o.
Do NOT increase RPM abruptly, let en-
gine run for 3 to 5 minutes in idle speed
so to stabilize pressure in the engine,
and bearings to lubricate. Do not let en-
gine run idle longer than 10 minutes, en-
gine may get damaged.
Starting will be interlocked if:
Roller is not braked.
Actuator 2 not in neutral.
STOP button pressed.
Driver not sitting on the seat.
