106 ASC110/ASC130/ASC150/ASC200/ASC250
2.8. Shifting the machine (transport)
1
2
1
2
• Unlock and pull pins (1) of two blocks (2) on both sides
from the joint. (options)
• Turn blocks (2) and secure with pin (1) and locking pin.
Do not step under the hanging load!
Return the safety arm and blocks to
default positions after loading is
complete.
Observe appropriate regulations while
loading and unloading the machine.
Use appropriate unimpaired tying
means of sufficient capacity.
Use appropriate crane of sufficient
capacity.
To tie the machine, use only lifting
eyes designed for the purpose.
Only a qualified slinger may attach
slings.
