Ammann ASC 130 - Loading the Machine

105ASC110/ASC130/ASC150/ASC200/ASC250
OPERATING INSTRUCTIONS
1
2
1
ASC 110
ASC 130*
ASC 150*
ASC 200
ASC 250*
2.8.4. Loading the machine
• Use drive-up ramps or crane to load the machine to a
transporting vehicle.
• The roller is equipped with lifting eyes for loading by
crane:
• Lock the joint against movements prior to lifting the
roller.
Joint locking:
• Unlock and pull pin (1).
• Fold arm (2) and secure it with pin (1) and locking pin.
