Ammann ASC 130 - Exchanging Oil in Gearboxes

162 ASC110 / ASC130 / ASC150
3.6. Individual Operations of Maintenance
1
1
2
3.6.25. Exchanging oil in gearboxes
Axle (wheel) gearboxes
• Place the roller onto a flat, firm surface so that the axle
gearbox plugs are in the position according to Fig.
Clean the area around plugs. Put appropriate vessel
under the drain plug (1). Unscrew both plugs and
clean them and drain oil.
• Àfter draining drive away with the roller so that the
plugs turn to the position.
• Fill oil through the upper plug (2) until the level reaches
the checking opening (1) or until it starts flowing out.
• Mount the plugs, replace damaged plug sealings.
Every 1000 Hours or Once a Year Every 1000 Hours or Once a Year
• Check the tensioner for clearance.
• Check the belt tensioner for clearances and for devi-
ation of the pulley from the vertical axis. Maximum
deviation is 3 degrees.
