Ammann ASC 130 - Vibratory Drum; Hydrostatic Drive of Travel

24 ASC 130
1.3. Technical Data
1.3.8. Vibratory Drum
ASC 130 D ASC 130 PD
Drum dia mm (in) 1500 (59,0) 1440 (56,7)
Drum dia over pads mm (in) - 1640 (64,6)
Drum width mm (in) 2200 (86,6) 2200 (86,6)
Drum shell thickness mm (in) 35 (1,38) 25 (0,98)
Number of pads - 140
Height of a pad mm (in) - 100 (3,93)
Area of a pad cm
2
(sq in) - 120 (18,6)
1.3.9. Hydrostatic Drive of Travel
Hydraulic pump of travel variable output with
skew plate, electrohydraulically controlled Sauer 90 R 075
Delivery per revolution cm
3
(cu in/rev) 75 (4,57)
Safety pressure MPa (PSI) 42 (6090)
Kontroller Sauer MCH
Drum drive gear-box (D; PD; HD; HDPD) Trasmital 709C3B75,5 H1
(HT; HTPD) Trasmital 710C3B75,5 H2
Filtration block Hytos 729-0060
Filter element Argo V3.0720-46
Drum drive hydromotor Sauer 51 C 060
Wheel gears (D; PD; HD; HDPD) Trasmital 707C2B33,3 H1
(HT; HTPD) Trasmital 707C3B53,3 H1
Hydraulic motors of wheel drives Sauer 51C060
The divider block Hytos 880-0303
