190 ASC110 / ASC130 / ASC150
3.8. Appendixes
Hydraulic circuit – ASC110/130/150 – INTER - Wheel differential lock
Diagram:
1 - Travel pump SAUER
2 - Vibration pump* REXROTH
3 - Drive drum hydromotor SAUER
4 - Vibration hydromotor** REXROTH
5 - Wheel hydromotors SAUER
8 - Steering pump REXROTH
9 - Power steering unit REXROTH
10 - Brake block HYTOS
11 - Steering hydraulic cylinder AXL SEMILY
12 - Divider lock HYTOS
13 - Switch 60 bar HYTOS
14 - Suction strainer HYTOS
15 - Filter DONALDSON
16 - Filler ARGO
17 - Hydraulic tank float
18 - Combined cooler EMMEGI
18 - One-way valve HYTOS
20 - Thermoregulator
21 - Check point STAUFF
22 - Quick-release coupling - male FASTER
23 - Quick-release coupling - female FASTER
24 - Quick-release coupling - male FASTER
25 - Temperature sensor
26 - Lifting electro-hydraulic generator SMA03 HYTOS
27 - Lifting hand hydraulic generator RC16 SAUER
28 - Lifting block HYTOS
29 - Hydraulic lock HYTOS
30 - Cabin lifting hydraulic cylinder AXL SEMILY
31 - Bonnet lifting hydraulic cylinder AXL SEMILY
* Rexroth A10VG 45 for ASC 110
Rexroth A10VG 63 for ASC 130/150
Sauer 90R042 for ASC 110 option
Sauer 90R055 for ASC 130/150 option
** Rexroth A10FM 45 for ASC 110
Rexroth A10FM 63 for ASC 130/150
Sauer 90M042 for ASC 110 option
Sauer 90M055 for ASC 130/150 option
