154 ASC110 / ASC130 / ASC150
3.6. Individual Operations of Maintenance
2
1
Every 250 Hours or Once in 3 MonthsEvery 250 Hours or Once in 3 Months
3.6.18. Checking oil in the vibrator
• Stop the machine on an even firm surface in order that
the plugs on the left side of the drum are in the position
according to fig.
• Clean the area around the checking plug (1).
• Unscrew the plug (1) and check the oil level. The oil
level must reach the checking opening or slightly flow
out.
• Refill oil after unscrewing filling plug (2).
• Clean the plugs and mount again.
! NOTE !
Refill the identical type of oil.
Check oil when it is cooled down.
Avoid leakage of oil to the soil.
